The large-tonnage roller frame is perfectly suitable for heavy industrial engineering. It has strong equipment carrying capacity, stable operation with variable frequency speed control, and effectively improves the quality of welding and forming.
More details contact us
Products introduction
Overview
- 80 ton welding rotator is heavy-duty industrial rotary welding equipment, specially designed for oversized and super heavy workpieces.
- Adopts reinforced welded steel structure, equipped with high load-bearing roller set and frequency conversion driving system.
- It supports stable rotating of tank, cylinder, wind tower and large pressure vessel, effectively improving welding efficiency and seam quality, widely used in heavy engineering manufacturing fields.
Key Points for Selection
How to select a welding rotator
Bearing Capacity: Confirm workpiece maximum weight, select proper tonnage model to avoid overload risk
Workpiece Diameter: Match roller spacing with part size to ensure stable supporting and rotation
Rotation Speed: Pick VFD speed adjustable type to fit different welding process requirements
Structural Type: Choose self-aligning or adjustable type based on production workpiece diversity
Roller Material: PU or steel roller optional, select according to wear resistance and anti-slip demand
Working Condition: Consider site space, operation mode and daily working duration for final selection
Product parameters
| Item | Specification |
|---|---|
| Rated Load | 80000kg |
| Applicable Workpiece Diameter | 800-4500mm |
| Rotating Speed | 0.1-1m/min, stepless adjustable |
| Roller Material | Wear-resistant PU/Steel roller |
| Drive Mode | Variable frequency drive |
| Structure Type | Self-aligning type |
| Overall Power | Customized matching power |
| Working Voltage | 380V 50Hz |
| Rotation Mode | Clockwise & counter-clockwise |
| Frame Material | Thick reinforced steel plate |
| Ambient Working Temperature | -10℃~50℃ |
| Warranty Period | 12 months |
product advantages
advantages
Heavy load bearing design, safely support 80-ton heavy industrial parts processing
Self-aligning roller structure, automatically correct workpiece offset during rotation
Low noise stable operation, effectively guarantee uniform and smooth welding seam
features
Wear-resistant anti-slip roller material, long service life and not easy to damage
Simple operation and easy maintenance, reduce later use and maintenance cost
Strict industrial manufacturing standard, strong adaptability for complex working site
Operation & Maintenance Guide
Operation Guide
Inspect parts and circuits beforehand, place workpiece stably and adjust speed smoothly.
Operate under rated load, cut off power timely when faults happen.
Maintenance Guide
Lubricate movable parts routinely and clean surface dirt regularly.
Coat anti-rust oil and keep dry storage while equipment standby.
Product Application
1.Pressure Vessel: Professional rotating welding of large storage tank and pressure vessel
2.Wind Power Industry: Forming welding of wind tower and wind power equipment components
3.Pipeline Engineering: Butt welding processing of large-caliber thick-wall pipelines
4.Steel Structure: Fabrication and welding of super heavy industrial steel structural parts
5.Heavy Machinery: Assembly welding of large mechanical shell and base parts
Product packaging
Company Certification
Customer feedback
Frequently Asked Questions
What is the maximum bearing weight?
+
-
The rated load reaches 80 tons, stable and safe for heavy workpiece rotation.
Can rotating speed be adjusted freely?
+
-
Supported VFD stepless speed regulation, speed adjustable according to welding demand.
Is it easy to adjust workpiece position?
+
-
Self-aligning design, automatically adjust position to avoid workpiece deviation.
What working environment is it suitable for?
+
-
Adapt to factory heavy production, stable performance under harsh working condition..
How long is the warranty period?
+
-
Whole machine enjoys 12 months standard quality warranty service.
