3D/2D Welding Fixture Table
Introduction
3D / 2D Welding Fixture Table is a modular tooling equipment designed for the welding process for accurate positioning, clamping and fixing workpieces to ensure the geometric accuracy and stability of parts during the welding process. It is widely used in automotive manufacturing, aerospace, heavy machinery, steel structure processing and other fields, significantly improving the welding efficiency and quality.
Products Parameters
Products Specification
Main Structure
of 3D/2D Welding Fixture Table
Subplate (Table Plate)
The surface is covered with regular threaded holes or positioning holes to form a standardized grid system for mounting fixture elements.
Positioning element (Locators)
Positioning pin, V-shaped block, corner seat, etc., is used to determine the reference position of the workpiece.
Cping element (Clamps)
Mechanical clamp, magnetic suction disk, fast clamp, etc., to provide a stable grip force.
Support element (Supports)
Adjustable height pillar, pad block, etc., to support the workpiece and prevent welding deformation.
Attachment system
Extension arm, rotary table, slide rail, etc., expansion clamp function to adapt to complex working conditions.
