3D Welding Table With Jigs
Product Description
Basic Definitions
3D Welding Table: A modular, multi - holed metal workbench with a surface covered with holes arranged in a standardized pattern (usually grid holes of φ28mm or φ16mm), used for precise positioning and clamping of workpieces.
Jigs: Special tools used in conjunction with 3D Welding Table. They are inserted into the holes of the platform to fix workpieces or assist in positioning, ensuring repeat accuracy during the welding process.
Products Parameters
product Specification
product key technologies
Of 3D Welding Table With Jigs
Automotive welding: Positioning of sub-assemblies of the white body (such as door hinge welding fixtures).
Aerospace: Vacuum electron beam welding fixtures for titanium alloy frames.
Teaching and training: A repeatable disassembly and assembly welding skill training platform.
Advantages compared with traditional fixtures
Time efficiency: The model changeover time is shortened by more than 70% (measured data).
Cost-effectiveness: The initial investment is high, but in the long term, 90% of the special fixture costs can be saved.
Accuracy maintenance: After wear, only a single fixture module needs to be replaced, without the need for overall scrapping.
Products Delivery
3D Welding Table With Jigs significantly improves the level of flexible welding production and is particularly suitable for fields with a high degree of customization, such as new energy battery packs and construction machinery. Typical user feedback shows that it can reduce the PPAP (Production Part Approval Process) preparation time for the welding process by more than 50%.
