CNC Gas Flame Cutting Machine

CNC Gas Flame Cutting Machine

According to the metal sheet material, thickness, dimensional accuracy, and processing surface requirements, choose flame cutting (steel plate 15mm or more), plasma cutting (steel plate 3--15mm), laser cutting (stainless steel), water jet cutting (aluminum), mechanical cutting (with High size requirements), molybdenum wire electrode discharge wire cutting (high-precision size requirements), etc.

Introduction

CNC Gas Flame Cutting Machine uses the heat of the high-temperature plasma arc to locally melt (evaporate) the metal at the incision of the workpiece, and uses the momentum of the high-speed plasma to remove the molten metal to form an incision. Unlike flame cutting, the plasma cutting speed is fast, especially for ordinary cutting. For carbon steel plate, the speed can reach 5-6 times that of oxygen cutting, and the cutting surface is smooth, the thermal deformation is small, and the heat-affected zone is small. Of course, CNC Gas Flame Cutting Machine is not limited to cutting carbon plates, it can also cut stainless steel, copper-aluminum materials and nickel-titanium metals.

Feature

1.Beijing START CNC operating system:

The SH2000F-CNC series numerical control system is produced by Beijing Star START Company.

It has superior functions, reliable quality and flexible matching.

It can meet the practical requirements of CNC flame cutting machines and has a high cost performance.

2.Planetary reducer (Taiwan brand)

3.Automatic ignition device

4.Professional programming software

5.Plasma cutting source

What the professional programming software do:

1. The processing of all steel plates,

2. Engineering drawing, engineering drawing input, optimized editing of files, automatic design of cutting path, optimized arrangement of batch parts

3. Cost accounting of materials, man-hours, losses, etc. during processing, and optimization of remaining materials.

4.More efficient drawing function than AUTOCAD

5.Can manually interrupt automatic nesting and manual discharging

6.Parts can be moved and rotated at will

Plasma cutting source:

Can be equipped with HUAYUAN 200IGBT or HUAYUAN 300 cutting source according to your requirements.

Main features of plasma power system:

1. Key components such as IGBT modules, fast recovery diodes, integrated circuits, relays, current and voltage regulators are all world-class brand-name products with high reliability;

2. The use of soft switching technology improves the working conditions of the IGBT tube and greatly improves the reliability of the IGBT;

3. When the ambient temperature is 40℃, the load duration is 100%, which is especially suitable for long-term, high-current and high-temperature environments.

1.Q:Are you a factory or trading company?
A: We are a factory.
2. Q:What are your payment terms?
A: We support T/T, L/C, Western Union and so on. Other ways can also be received after we both sides discussion and agreement. Any other questions contact us directly!
3. Q:How about the warranty?
A: There are 12 months for the warranty.
While the warranty is not responsible for those broken by violence
4.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Jiangsu Wuxi(next to Shanghai),China.You can fly to Shanghai airport directly.All our clients, from home or abroad, are warmly welcome to visit us!
