Horizontal Type H Beam Welding Machine
The traditional h -beam welding line (mainly for vertical Assembly and boat-shaped welding) the existence of welding deformation and low production efficiency, lightweight h -beam welding effect is far from ideal, we developed the h steel horizontal welding production line.
Products parameters
Web height: 300-1500 mm
Web thickness: 3-8 mm
Flange width: 150-500 mm
Flange thickness: 5~16 mm
Application of workpiece length: 4000~15000 mm
Max weight: 4000 kg
Tapered angle: ≤8°
Products features
1. Group immediately only on the workpiece end spot (without workpiece length spot welds), you can enter the finishing and welding, welding machine and then the three-block "sanban" position for welding, the Group greatly improved the effectiveness of legislation.
2. Using the horizontal workpiece (h steel Web standard, flange plates erected), moving the welding mode, two seam while welding can be realized, in order to reduce the heat-induced distortion of the workpiece.
3. Configure, so welding power source, double wire single arc welding, using 1.6mm fine welding wire, welding speeds of up to 1.2 m / min, weld is good, pleasing in appearance.
4. Due to the degree of automation production line of more traditional lines are greatly improved, so it can reduce labor intensity and reduce the operator, the line is only 4-5 operator to normal production.
5. And adaptable ≤8° tapered h- section steel processing.
Products package
