Welding Fixture Plate
Welding fixture plate is a special tool used to fix, position and clamp workpieces during welding, ensuring the accuracy, consistency and efficiency of welded parts. The following is a detailed introduction:
Definition and function
Definition: A welding fixture plate is a rigid platform or modular system, usually with standardized holes or slots, for mounting fixture components (such as locating pins, clamps, support blocks, etc.) to fix the workpiece and keep it in the correct position.
Function:
Positioning accuracy: Ensure the relative position of multiple workpieces or components is accurate during welding.
Reduce deformation: Reduce welding thermal deformation through uniform clamping force.
Improve efficiency: Fast clamping, suitable for mass production.
Repeatability: Ensure the consistency of parts produced on the same fixture.
Products Parameters
product Specification
Lemar Best Products
Main components
Base Plate:
Material is usually high-strength steel, aluminum alloy or composite material, and the surface is heat-treated for wear resistance.
With matrix threaded holes (such as DIN standard holes) or T-slots for fixing fixture components.
Location elements:
Location pins: accurately determine the position of the workpiece.
V-Blocks: fix cylindrical workpieces.
Clamping mechanism:
Quick clamps, hydraulic/pneumatic clamps.
Support structure:
Adjustable support rods, gussets to prevent workpieces from sagging or deflecting.
Auxiliary components:
Cooling channels (reduce thermal effects), anti-splash coating (protect the fixture).
Products Delivery
The welding fixture plate is a key tool in modern welding technology. Through standardized and modular design, it significantly improves welding quality and production efficiency, and is especially suitable for high-precision, mass production scenarios. When choosing, you need to balance flexibility, cost and durability according to specific needs.
