3D Modular Welding Table With Clamps
3D Modular Welding Table With Clamps is a complete system integrating a high-precision reference platform and quick positioning and locking tools. Its main body is a tabletop with precision grid holes (usually square or round holes) arranged in a regular matrix, and "with clamps" means that the system also provides a series of specially designed standardized clamps, support blocks, angle devices and other accessories used in conjunction with the hole system of the tabletop.
Products parameters
Products Specification
Core Components and Features
--3D Modular Welding Table With Clamps
★ Main Body: 3D Modular Welding Tabletop
• Precision Grid Tabletop: The holes on the tabletop (such as 28mm series square holes, φ28mm round holes) are precision-machined with consistent hole spacing and minimal errors in positional accuracy and perpendicularity, serving as the precision foundation of the entire system.
• 3D Expandability: The modular design allows the tabletop itself to be horizontally spliced with connectors to expand its area, and functional modules can be arbitrarily combined in three-dimensional space on it.
★ Soul: Specialized Fixtures and Modules
This is the key value of being "equipped with fixtures". The supporting fixtures usually include:
• Quick Locking Fixtures: Such as cam lever fixtures and spiral compactors, which can clamp and release workpieces within seconds through simple handle operations.
• Positioning and Supporting Modules:
◦ Right-angle Stops: Used to quickly establish a 90-degree reference.
◦ Locating Pins/Diamond Pins: Used for precise positioning of workpieces.
◦ Supporting Blocks and Pillars of Various Heights: Used to support and level workpieces in the Z-axis direction.
◦ Angle Adjustment Modules: Used to clamp workpieces with specific angles.
• System Compatibility: The bottom of all these fixtures is designed with positioning keys or threads that perfectly match the hole system of the tabletop, ensuring quick and accurate installation at any position on the tabletop.
★ Summary of Core Features
• Ready to Use, Quick Start: Users do not need to design and purchase fixtures separately, reducing the entry complexity.
• High Precision and Repeatability: All positioning and clamping are based on the same precision reference, ensuring clamping accuracy and consistency in mass production.
• Unparalleled Flexibility: Through a limited number of standard fixtures, infinite clamping schemes can be combined to adapt to workpieces of different shapes and sizes.
• Significantly Improved Efficiency: Compared with the cumbersome marking, spot welding, and use of C-clamps in traditional welding, the clamping speed can be increased several times.
Products Advantages
Core Advantages
►Lower initial technical threshold: Provide users with verified and well-matched combinations of worktops and fixtures, avoiding the risk of improper self-matching.
► Achieve immediate productivity: The time from when the equipment is in place to producing the first high-quality workpiece is minimized.
► Controllable costs and clear investment: As a standard set, its price and included contents are clear, facilitating purchasing decisions and cost accounting.
► Lay the foundation for future expansion: 3D Modular Welding Table With Clamps is the starting point of modularization, and users can purchase more similar standard fixtures at any time in the future as needed to enhance capabilities.
Customer Review
Product Certification
FAQ
FAQ
01.What's the lead time for orders?
02.What documents do you provide for export?
03. How do I place an order?
04.Which payment methods are supported?
3D Modular Welding Table With Clamps, in essence, is not selling a "product" but a kind of "immediately effective flexible production capability".
It solves the "first step" problem in the transition from traditional fixed tooling to modern modular tooling. For small and medium-sized enterprises, start-up teams, or departments that have just been exposed to advanced manufacturing concepts, this is an entry-level option with the lowest risk and the fastest results. It perfectly interprets the core value of the modular system - using standardized components to cope with non-standardized manufacturing challenges, and it is a powerful toolkit to improve the workshop's response speed, processing accuracy and comprehensive competitiveness.
