D28/D22/D16 3D Welding Table

Introduction

3D welding workbench is a modular, high-precision tooling platform, specially designed for welding, assembly, testing and other processes, especially suitable for the efficient positioning and clamping of complex workpieces. D28, D22, D and 16 usually refer to the hole specification (aperture size) of the workbench, representing different positioning accuracy and carrying capacity.

Structure
Modular design: composed of high strength cast iron or steel substrate with standardized positioning holes (28mm aperture for D22 2 mm for D 22, D16 for 16mm), which supports rapid combination and adjustment.
3D hole system: hole positions are distributed according to the standard grid (e. g. 5050mm or 100100mm) and support positioning and clamping in 3D orientation (X / Y / Z).
Adjustable fixture accessories: with a variety of fixtures (such as pressing pliers, support column, Angle block, etc.), to adapt to different shapes and sizes.

Products Parameters

Welding Jig Table

Products Specification

Model difference and type selection recommendations

D28 (28mm aperture):
Advantages: strong carrying capacity, suitable for large, heavy workpieces (such as construction machinery structural parts).
Applicable scenario: heavy industry, large welding projects.
D22 (22mm aperture):
Balanced type: both strength and flexibility, suitable for small and medium-sized workpieces and general welding requirements.

D16 (16mm aperture):
High precision type: more dense hole spacing, suitable for precision welding or small complex parts (such as electronic equipment support, precision instrument parts).
