Brief Introduction
20 Ton self aligning pressure vessel turning rolls for girth welding of boilers, tanks and cylindrical vessels.
Automatic centering design, PU anti-scratch rollers and VFD speed control. Suitable for pressure vessel manufacturing.
Complete CE documents, factory direct supply.
Technical Parameters
| Item | Specification |
|---|---|
| Model | ZTG-20 Pressure Vessel Turning Rolls |
| Rated Load | 20 Ton |
| Applicable Workpiece Diameter | 500 mm – 3500 mm |
| Roller Material | PU Roller / Cast Steel Roller Optional |
| Control Mode | VFD Stepless Speed Regulation |
| Custom Voltage | 380V/400V/415V/480V Optional |
| Usage | Pressure Vessel, Boiler, Tank Girth Welding |
Core Advantages
Automatic self-centering roller design, greatly shorten equipment adjustment time for multi-specification workpieces.
Dual-motor synchronous driving system, stable operation under 20 ton heavy load without slipping.
PU anti-scratch rollers, effectively avoid surface damage to stainless steel pressure vessels.
Application Scope
✅ Medium & Large Pressure Vessel Production
Suitable for girth welding of medium and large tanks in pressure vessel manufacturing factories.
✅ Chemical Equipment Fabrication
Used for rotary welding of chemical storage tanks and reaction vessels.
✅ Boiler Component Processing
Ideal for fabrication of boiler barrels, headers and other cylindrical boiler parts.
✅ Metallurgy & Pipeline Manufacturing
Fit for processing all types of cylindrical structural workpieces in metallurgy and pipeline industry.
Working Principle
1.Consist of driving unit and driven unit to jointly support cylindrical pressure vessel workpieces.
2.Roller support angle automatically swings to realize self-centering according to workpiece outer diameter.
3.Frequency converter controls driving motor to achieve stable constant-speed rotation.
4.Realize continuous circumferential welding by rotating pressure vessel instead of moving welding torch.
Quality Assurance
- Wireless remote control pendant for convenient on-site operation.
- Signal linkage interface to connect welding manipulator and welding machine.
- High temperature resistant cast steel rollers for high-temperature workpiece welding.
- Extended base frame to adapt longer cylindrical pressure vessels.
Product packaging
Company Certificate
Frequently Asked Questions
Q1: Can this 20 Ton Pressure Vessel Turning Rolls work with stainless steel tanks?
+
-
A1: Yes. It can be equipped with PU anti-scratch rollers to protect stainless steel surfaces from abrasion during rotary welding.
Q2: Is the roller position manually adjusted for different cylinder diameters?
+
-
A2: No. This is self-aligning type. The roller group automatically swings to center the workpiece without repeated manual adjustment.
Q3: Can the machine support custom industrial voltage for overseas projects?
+
-
A3: Yes. We support 380V, 400V, 415V, 480V and other customized voltages to meet requirements of different countries.
Q4: Can the turning rolls connect with welding manipulator and automatic welding machine?
+
-
A4: Yes. Optional linkage interface is available to realize coordinated operation with welding equipment for automatic girth welding lines.
Q5: What is the applicable workpiece diameter range for this 20T turning rolls?
+
-
A5: This pressure vessel turning rolls fits cylinder workpieces from 500mm to 3500mm diameter, covering most conventional boiler and pressure vessel welding demands.
