2D Modular Welding Table
2D Modular Welding Table is a precision tooling equipment designed for welding, assembly and fixture positioning. It is widely used in the manufacturing industry for its modularity, high precision and flexibility.
Product Description
Definition and core features
Modular design: It consists of a flat plate with standardized grid holes (such as D28 or D16 series) and detachable accessories. Users can freely combine components such as fixtures and positioning pins according to their needs.
High precision: The surface of 2D Modular Welding Table is finely processed, and the hole position tolerance is usually controlled within ±0.02mm to ensure positioning accuracy.
Two-dimensional plane operation: It is mainly used for plane welding and assembly, suitable for the processing of plate-shaped or frame-type workpieces.
Products Parameters
product Specification
2D Modular Welding Tables' product key technologies
Core Advantages
Quick production change: adapt to different workpiece processing by changing the fixture module, reducing downtime.
Repeatability: modular hole system design ensures consistency of multiple clamping.
Cost-effectiveness: reduce the need for customized tooling and reduce production costs.
Durability: the surface is often hardened to resist wear and welding spatter.
Selection considerations
Hole system standards: such as the D28 commonly used in Europe or the D16 system popular in Asia.
Dimensions: Select 2D Modular Welding Tables' size according to the size of the workpiece (commonly 1m×2m to 2m×4m).
Material requirements: Cast iron is suitable for high precision, and steel is more impact-resistant.
Products Application
Small batch and multi-variety production: such as automotive parts and steel structure welding.
Education/R&D: used for welding technology training or prototype development.
Maintenance field: positioning and repair of complex parts.
Products Delivery
2D Modular Welding Table balances precision and efficiency through standardization and flexibility. It is particularly suitable for small and medium batches and multi-variety precision welding scenarios, and is an important part of the modern flexible manufacturing system. For complex workpieces that require stereo positioning, it is necessary to upgrade to a 3D system.
