Precision 3D Modular Fixture Platform
Precision 3D modular fixture platform is an industrial tooling solution that rapidly constructs a repeatable positioning fixture system in 3D space through precision modular components based on high-precision standardized interfaces.
Core connotation: It provides a "precision benchmark reconstruction system" for the manufacturing industry, transforming the single function of traditional customized fixtures into a precision manufacturing foundation that can be rapidly reconstructed as products change.
DM Eva directly for quotation and more details↓↓↓
Products Types
Products Size
1. Precision Advantages
• Eliminate cumulative errors: All positioning is based on the same datum, avoiding the accumulation of errors from multiple clamping operations.
• Ensure batch consistency: High repeat positioning accuracy ensures stable quality of mass-produced products.
• Serve as a measurement datum: Modular welding table itself can be used as an on-site measurement datum besides coordinate measuring machines.
2. Efficiency Advantages
• Rapid model changeover: Fixture reconfiguration time can be reduced by 70-90% compared with traditional methods.
• Parallel design: Process design and fixture design can be carried out simultaneously.
• Reduce debugging time: Precise datums reduce on-site debugging workload.
3. Economic Advantages
• Amortization of initial investment: One system can replace dozens of sets of special fixtures.
• Low lifecycle cost: Modules can be reused for decades.
• Simplified warehouse management: Unified management of modular components reduces warehouse space.
4. Quality and Flexibility Advantages
• Process optimization capability: Facilitates process testing and optimization.
• Support for small-batch production: Makes small-batch precision manufacturing economically feasible.
• Knowledge encapsulation: Solidify process experience into modular solutions.
Products Workflow
Main Workflow
1. Physical Construction Phase
• Datum Establishment: Clean welding fixture table and install the main positioning datum components
• Layered Construction: Install supporting and positioning components in accordance with the principle of "from bottom to top, from inside to outside"
• Accuracy Verification: Use measuring tools to verify key dimensions and fine-tune to meet design requirements
• Clamping System Installation: Install clamping components last to avoid over-positioning
2. Production Application Phase
• First Article Verification: Measure the key dimensions of the first article product
• Process Solidification: Record successful fixture configuration schemes
• Mass Production: Operate stably and check the accuracy status regularly
3. Reconfiguration and Maintenance
• Orderly Disassembly: Disassemble components in the reverse order of construction
• Cleaning and Maintenance: Remove welding slag and oil stains, and check for wear
• Precision Re-inspection: Regularly inspect the flatness of the platform and the accuracy of hole positions
