3D welding table jigs is a modular tool designed for precise positioning and fixation of workpieces during welding. Its core function is to improve welding efficiency and accuracy, especially for the assembly of complex structures.

Core structure and components

Modular orifice plate

The main body is a steel plate or aluminum alloy plate with regular matrix holes (such as a spacing of 28mm). The hole positions are compatible with standard fixture elements and support multi-angle fixation.

Positioning element

Including dowel pins, quick clamps, magnetic bases, etc., which can quickly lock the workpiece position and ensure alignment tolerance (usually within ±0.1mm).

Extended support

Angle block, universal joint, telescopic arm and other components, to adapt to curved or shaped workpiece, reduce welding deformation.

This type of fixture solves the problems of high rigidity and poor adaptability of traditional welding tooling through modular design, and has become a key tool for modern welding workshops to enhance process flexibility.



products Details

core advantage



Flexible adaptation:

No need for custom tooling, saving costs and time.



Repeatability:

Modular design ensures consistency across multiple clamps.

Efficient heat dissipation:

Metal material is resistant to high temperature (e.g. Q235 steel can withstand more than 800 ° C).

Products Display
