CNC End Face Milling Machine
CNC End Face Milling Machine is composed of milling head, lifting column, worktable, bed, mechanical supply system, electrical control system and guide rail protection device. It is suitable for end cutting of metal materials such as castings and steel parts, and is widely used in machine manufacturing.
Products Display
Products Features
The face milling machine can mill the workpiece plane, chamfered trapezoidal surface and T-slot. The drilling hole can reach φ50mm and the boring hole can reach φ400mm.
After installing the matching sliding table, milling, drilling, boring and special surface processing can be performed on both ends of the super long workpiece.
The milling force is strong and can meet the processing requirements of the parts.
The movement of the worktable adopts planetary gearbox for variable speed, and the operation is flexible and convenient.
The column lifting adopts a counterweight unloading device, which can easily move up and down, which not only prolongs the service life of the screw, but also makes the cutting smooth.
The milling adopts helical gear transmission, the cutting and milling surface precision is high, and the noise is low. After installing the frequency conversion device, it can be continuously variable.
The whole machine has strong rigidity, is not easy to be damaged, convenient maintenance, diverse functions, and large geometric dimensions. It is an ideal equipment for mechanical processing.
The DX series end milling machine can generally be divided into the main part of the end milling machine and the part of the workpiece clamping table. Users can order separately according to the actual situation.
