Weld Fixturing Tables
Weld Fixturing Tables are modular fixture platforms specifically designed for the welding process. They are used to accurately position, clamp, and fix workpieces, ensuring that components remain stably aligned during the welding process.
Their core functions include:
Positioning accuracy: Millimeter - level repeatable positioning is achieved through a standardized hole/slot system (such as DIN/ISO standards).
Quick change - over: Modular fixtures (such as hydraulic, magnetic, or mechanical clamps) can be quickly adapted to different workpieces.
Rigid support: High - load steel structures (usually HT250 cast iron or steel) resist welding thermal deformation.
Products Parameters
product Specification
Lemar Best Products
Key Structures and Technical Features
Worktable Surface:
Material: High-strength cast iron (good shock absorption) or pre-stretched steel (good welding compatibility).
Hole Pattern System: 28mm array holes (standard DIN 6325) or 16mm/20mm grid holes with a pitch of 50 - 100mm.
Surface Treatment: Hard anodization or galvanized coating (spatter-resistant/corrosion-resistant).
Fixture System:
Types: 3D modular fixtures (such as EROWA), permanent magnetic fixtures (suitable for thin plates), pneumatic clamping (for mass production).
Degrees of Freedom: 5-axis adjustable fixture arm, supporting ±15° angle fine-tuning.
Extended Functions:
Integrated CLAMP-TITE System: Synchronous locking of multiple fixtures is achieved through a hydraulic pump.
Automation Interface: The mounting surface for the seventh-axis guide rail of the robotic welding arm.
Through reasonable selection and use, Weld Fixturing Tables can increase welding efficiency by more than 300% (ESAB research data) and reduce assembly errors by 90%. For high-mix production environments, it is recommended to choose a solution equipped with the QMC (Quick Modular Change) system.
