Product Overview
Widely applicable to pipe flange welding, small hardware parts, cylindrical components and miniature tank welding, this portable welding positioner is an essential arc welding auxiliary machine for small and medium welding workshops. It greatly improves welding efficiency, optimizes weld forming quality, reduces manual operation intensity, and is the preferred industrial welding turntable for precision small workpiece welding.
Product parameters
|
Model |
BWJ-3 |
BWJ-12 |
BWJ-20 |
BWJ-30 |
BWJ-40 |
BWJ-50 |
BWJ-80 |
BWJ-100 |
BWJ-150 |
|
Loading(kg) |
300 |
1200 |
2000 |
3000 |
4000 |
5000 |
8000 |
10000 |
15000 |
|
Rotating speed(r/min) |
0.2-2 |
0.03-0.3 |
0.02-0.2 |
||||||
|
Tilt speed(r/min) |
0.18 |
0.37 |
0.25 |
0.2 |
0.15 |
||||
|
Turning table height(mm) |
700 |
1250 |
1250 |
1600 |
1600 |
1800 |
1800 |
2100 |
2300 |
|
Tilt angle(°) |
0-90 |
0-90 |
0-120 |
0-135 |
0-135 |
0-135 |
0-135 |
0-135 |
-45-90 |
|
Table diameter(mm) |
600 |
1200 |
1250 |
1400 |
1500 |
1500 |
1600 |
2000 |
2000 |
Application scope
Pipeline Fittings Welding:
Professional for pipe flange welding, pipe joint and small pipe fitting circumferential seam welding
Hardware Component Processing:
Rotary welding, polishing and flaw detection of mechanical parts, hardware accessories and structural components
Small Vessel Fabrication:
Welding and forming of small tank welding turntable applicable miniature storage tanks and cylindrical containers
Precision Welding Production:
Batch processing of small cylindrical workpieces, vertical and horizontal all-position welding forming
Product Core Advantages
VFD Stepless Speed Regulation: Adopts high-performance frequency converter for smooth soft start and soft stop. This VFD speed control positioner supports stepless speed adjustment to match diverse welding processes with no impact on workpieces.
Compact & Portable Structure: This compact welding positioner features small footprint and lightweight design. It is flexible to move, easy for workshop layout and multi-station switching.
Stable & Durable Performance: Integral cast steel frame ensures deformation resistance and wear resistance. Precisely processed transmission parts guarantee low failure rate and long service life for continuous batch welding.
Product packaging
Customer feedback
Company Certification
Frequently Asked Questions
Q1: What is the load capacity of this welding positioner?
+
-
A1: This is a 300kg light duty welding positioner, suitable for various small and light workpieces within 300kg.
Q2: Can the rotation speed and angle be adjusted freely?
+
-
A2: It adopts VFD stepless speed control, with 0-120° arbitrary tilting angle adjustment, flexible and convenient for various welding processes.
Q3: Is it suitable for flange and small pipe welding?
+
-
A3: Absolutely. It is specially designed for pipe flange welding and small cylindrical workpiece circumferential seam welding.
Q4: Is the equipment easy to operate for new workers?
+
-
A4: Equipped with simple button control system, easy to learn and operate, suitable for workshop batch production.
Q5: What is the service life and after-sales service?
+
-
A5: The equipment is sturdy and durable with low failure rate. We provide professional installation guidance, technical support and long-term spare parts supply.
