Oxy Fuel And Plasma Cutting Equipment
Products Description
Oxy fuel and Plasma cutting equipment for steel structures has two Driving form: Single side/Double side
Rail gap:3000mm-10000mm
Effective cutting width:2100mm-9100mm
Flame Cutting Thickness:6-200mm
Plasma Cutting Thickness:6-30mm
Cutting method:Plasma
Max speed:6000-12000Mm/min
Products Features
USB Port for Program transfer
Large inbuilt memory for program storage
Standard Shape Library
Basic grid nesting on the CNC
Easy access control panel switches
Driven with Dual Drive (Y) Servo System with Precision Planetary gearbox with Anti Backlash mechanism
High Quality rails ensure stable and high speed performance
Precision Rack & Pinion Drives on X and Y Axis
Equipped with fine plasma cutting torch,and the torch diameter ф50mm,Other companies are equipped with ordinary guns, the gun diameter is ф40mm.
The 9 groups of straight gas cutting torches have electric simultaneous lifting function to reduce the thickness change of the cutting steel plate and adjust the time of straight bar guns one by one to improve cutting efficiency.
By adjusting the angle of the straight bar gun, both sides of the cut bar can be beveled up and down at the same time to improve the beveling efficiency.
Any size of your plates please kindly feel free to contact Wuxi Lemar directly.
