Reusable Welding Fixture Table for Metalwork
what is Reusable Welding Fixture Table?
A reusable welding workbench is a highly modular and standardized auxiliary equipment for metal processing. Its core is a tabletop made of high-precision cast iron or steel, which is covered with regularly arranged standardized hole systems (usually grid-shaped). Combined with a series of precisely positioned modular fixture components (such as stoppers, angle devices, clamps, support blocks, etc.), it can quickly and flexibly construct a three-dimensional fixture system for positioning and clamping metal workpieces of various shapes and sizes. After welding is completed, the fixture components can be disassembled and reconfigured for the next workpiece, realizing the concept of "one set of fixtures, infinite combinations".
high quality
advanced equipment
professional team
global shipping
Operational Process for Reusable Welding Fixture Table
| Step | Procedure | Key Actions / Description |
|---|---|---|
| 1 | Preparation |
Clean the table surface to ensure it is free of weld spatter and dust. Prepare the required fixture components. |
| 2 | Analyze Workpiece Drawing |
Identify the workpiece's datum features, clamping points, and ensure welding accessibility. |
| 3 | Fixture Design (Optional) |
For complex workpieces, pre-plan the component layout using CAD software or dedicated simulation systems. |
| 4 | Assemble Fixture System |
a. Mount positioning blocks, support seats, etc., onto the table's grid holes using dowel pins and T-bolts (or stud bolts). swing arms) to secure the workpiece firmly with appropriate force. |
| 5 | Load & Clamp Workpiece | Place the workpiece onto the assembled positioning system and apply clamping force. |
| 6 | Welding Operation | Perform the welding process. |
| 7 | Disassembly & Cleanup |
After welding, release clamps and remove the workpiece. Dismantle fixture components, store them categorically, clean the table surface, and prepare for the next setup. |
Our Service Processes
Our free service hotline:+86 159 952 699 47(Eva summer)
Pre-sales Consultancy
1
>>
Confirmation of order
2
>>
Production
3
>>
Multi-Channel Shipping
4
>>
Confirmation of receive
5
>>
After-sale Services
6
Product Features
• Modularity and flexibility: These are its core features. Through different combinations of standard components, it can meet the production needs of multiple varieties and small batches.
• High precision: The tabletop undergoes precision machining, with extremely high flatness and hole spacing accuracy (usually reaching ±0.05mm/m), ensuring precise positioning of the assembled fixtures and workpieces.
• High repeatability: Modular components and standardized hole systems ensure consistency in each assembly and repeated assembly, making it very suitable for mass production.
• Reconfigurability: One system can serve countless types of products, eliminating the need to separately design and manufacture special fixtures for each new product, thus saving a lot of costs and storage space.
• Strong durability: The main body is made of high-strength materials and undergoes heat treatment, featuring wear resistance, deformation resistance, and a long service life.
Usage Notes
• Safety First: When hoisting heavy workpieces or using pneumatic/hydraulic clamps, strictly comply with safety regulations.
• Heat and Spatter Protection: Avoid prolonged high-heat welding at the same position on the tabletop. Use splash guards or copper pads to protect the tabletop and component threaded holes.
• Regular Cleaning: Welding spatter and dust falling into holes can seriously affect precision and usability. Use special tools (such as hole plugs, air guns) for timely cleaning.
• Proper Storage of Components: After use, components should be cleaned, coated with anti-rust oil, and stored in dedicated toolboxes or shelves for easy access and management.
