Steel H Beam Assembling Machine
Products Description
Steel H Beam Assembling Machine is a piece of equipment used to assemble steel H-beams. H-beams are a common type of structural steel often used in buildings, bridges, and other heavy projects. The main function of this machine is to precisely assemble the various components of the H-beam to ensure the stability and strength of the beam.
Product Details
1.Machinery stationary,beam automaticly through
2.Applicable beam specifications:
Web height:200-2000mm
Flange width:200-800mm
Beam length:4000-15000mm(We can do machines according to your needs,height can be up to 3000mm)
3.Hydraulic system:has pressure keep and time delay function
4.Main drive control:AC Motor+Cycloidal reducer
5.Adopt imported technology of frequency converter to AC Frequency convertor centralizes and locates the web and flange,to realize the automatic welding.
6.Gas shield welding or manual welding are both available for user.
Feature
Steel H Beam Assembling Machine is efficient, precise and stable. It can greatly improve the production efficiency of steel H-beams, reduce the need for manual operations, and improve product quality and consistency. This machine can also be adjusted and customized according to different beam sizes and requirements to meet the needs of different projects.
1. Helps minimize the need for physical labor. This in turn increases the overall productivity of construction projects and increases the speed and quality of the finished product.
2. These machines operate with extremely high precision, ensuring H-beams are assembled perfectly every time. This helps reduce any errors or inaccuracies during the construction process that could lead to safety issues or construction delays.
3. Wide range of uses. They can be used on a variety of construction projects, from small residential buildings to large commercial buildings. This flexibility allows construction companies to maximize their investment in machinery and get more use over time.
4. Little impact on the environment. Since these machines are designed to minimize waste and increase efficiency, they help reduce the amount of resources required for construction work. This makes them an environmentally friendly choice for any construction site.
Products structure
Such H beam flange and web assembly machines usually consist of several main parts. The first is the beam positioning system, which can accurately position and fix the various components of the beam to ensure that they are in the correct position. Next is the welding system, which uses high-temperature welding technology to firmly connect the components of the beam body together. There are also conveyor systems to move the beam components from one work station to the next for successive assembly and welding operations.
